Pre-sale: WH52 Soil Moisture/Temperature/EC Sensor, Wireless 3-in-1 Soil Sensor

$27.99 USD
$27.99 USD $27.99 USD
Shipping is calculated at checkout. (For EU customers: For parcels shipped via [Standard], VAT is included.)
Radio Frequency: North America MHz 915
How to choose frequency
Batch: Third batch (Ships late June to early July)
ecowittEcowitt WH51L Wireless Soil Moisture Meter with 1M/5M PVC Wire – Soil Sensor with Display, AD Value, and Real-Time Monitoring for Garden, Farm, and Greenhouse
Ecowitt WH51L Wireless Soil Moisture Meter with 1M/5M PVC Wire – Soil Sensor with Display, AD Value, and Real-Time Monitoring for Garden, Farm, and Greenhouse
WH51 Wireless Soil Moisture Meter – Soil Moisture Sensor for Irrigation Management, Garden, and Agriculture
ecowittWH51 Wireless Soil Moisture Meter – Soil Moisture Sensor for Irrigation Management, Garden, and Agriculture
$27.99 USD
$27.99 USD $27.99 USD

Pre-sale Shipping Information:

  1. The first batch is expected to ship in February 2026, most of the second batch between late May and early June 2026 (Orders from the second batch placed before May 29, 2026 will be shipped starting June 2. Pre-orders from the second batche placed after May 29, 2026 will be shipped after the end of June), and the third batch between late June and early July 2026. The different batches only refer to different production times, while the manufacturing process and quality remain the same. Any updates or changes will be communicated promptly.
  2. If the product becomes available on Amazon during this period, you may also consider placing the order through Amazon.


Key Features:

Note: The WH52 sensor requires a gateway or console for data display.

  1. Multi-Parameter Measurement: Measures soil moisture, soil temperature, and electrical conductivity (EC).
  2. Soil Temperature Sensor: High-precision NTC thermistor closely contacts soil particles to capture the temperature actually perceived by roots.
  3. Soil Electrical Conductivity Sensor: Dual-electrode measurement determines total soluble salts in soil solution (μS/cm).
  4. Data Transmission & Channel Sharing: Sends data every 70 seconds to a gateway or console; shares 16 soil moisture channels with WH51/WH51L (8 channels for HP350x, WN1900/1920).
  5. Connectivity & Remote Access: Once paired with a gateway, historical data and alerts for abnormal conditions can be viewed via the ecowitt App or ecowitt.net; supports data upload to Ecowitt, WU, WOW, or a custom server.
  6. Compact & Durable: IP66-rated for outdoor use; plug-and-play design.
  7. Power Management: Powered by 1 AA battery (not included) with low-power design; each device has a unique Sensor ID for easy registration and management in the ecowitt App.

Compatible gateways / consoles (Wi-Fi and/or Cellular):

GW1100/GW1200/GW2000/GW3000/HP2550/HP2560/WS3800/WS3820/WS3900/WS3910/WN1920/WN1980/WN1820/WN1821/WN1700

Note:

1. The sensor may share the same channels with other sensors of the same type.

2. Some data is cloud-only and not available on compatible consoles.

3. Compatibility may change with product updates. Please refer to the latest compatibility table(at the bottom of the product page) or contact us for confirmation.

Specifications

Model WH52
Name 3-in-1 Soil Sensor
Dimensions 148 x 86 x 25mm
Material of Housing ABS
Material of Probe FR-4(Glass Fiber Reinforced Epoxy)
Measurement Principle Frequency Domain Reflectometry
Moisture Range 0~100%
Moisture Accuracy ±5%
Moisture Resolution 1%
Temperature Range -40~60℃(-40~-140℉)
Temperature Accuracy ±1%℃
Temperature Resolution 0.1℃
EC Range 0-10000μS/cm
EC Accuracy 0-1000μS/cm ±100μS/cm；1-1000μS/cm ±15%
EC Resolution 10μS/cm
Device Operating Range -40~60℃
0%AD setting range 0~200; Initial value: default to factory calibration
100%AD setting range 0%AD+10~1000; Initial value: default to its factorycalibration
Frequency 915/868/433MHz depending on location
(North American:915MHz; Europe:868MHz; Other
areas:433MHz)
Sensor reporting interval 70 seconds
Transmission distance in open
field		 100m(300 feet)
IP Rating IP66
Power Supply 1xAA battery (not included)
Battery life Minimum 12 months


Parts List

1 x WH52 Soil Moisture/Temperature/EC Sensor(NO display console)
2 x Cap cover(One long and one short)
1 x User Manual

Note: Battery not included.

[WH52 Manual](https://s.ecowitt.com/2W1W5B)

Compatibility Instructions

for all ecowitt network consoles

Please refer to the table to choose the correct sensors and consoles before checkout.
Note:
1) "1/4/8/16" = max number of sensors supported per console (excluding accessories).
2) Upload only = sensor readings shown only in the Ecowitt app and cloud (www.ecowitt.net).
3) Firmware (e.g. V1.9.6 / V2.0.2) = gateway/console must run this version or newer.
