Features
Sensor: Piezoelectric rain gauge; Ultrasonic wind speed, gust speed,
and wind direction; Temperature; Humidity; Solar light intensity and UV index;
Waterproof IPX5;
Services
Need a console to use.
Specifications (Sensor)
Measurement | Range | Accuracy | Resolution |
Wind speed | 0m/s to 40m/s | <10m/s, ±0.5m/s; ≥10m/s, ±5% | 0.1m/s |
Wind direction | 0° to 359° | <2m/s, ±10°; ≥2m/s, ±7° | 1° |
Temperature | -40°C to 60°C | ±0.3°C (± 0.6°F) | 0.1°C (± 0.2°F) |
Humidity | 1% to 99% | ±3.5% | 1% |
Light | 0Klux to 200Klux | ±15% | 0.1Klux |
UVI | 1 to 15 | ±2 | 1 |
Rain | 0 to 9999 | TBA | 0.1mm |
Sensor solar panel (built-in): 6.5V/4mA
Sensor (backup): 2 x AA 1.5V battery (not included)
Transmission between gateway and sensor
Transmission distance in open field: 150 m (500 ft.) depend on environment
RF frequency: 433/868/915/920 MHz depending on location
Sensor reporting interval: 8.8 seconds
Parts List
1* WS90 sensor
1* User manual
Additional or optional or extra or compatible with Console (sold separately):
WS90 supports console GW1100, GW2000, HP2550, HP2560, HP3500, WN1900, WN1910, WN1920, WN1980, WN1820, WN1821, WS3800, WS3900, WS3910, GW1200;
Measurements | ||
---|---|---|
UV Index / Solar Radiation |
|
|
Display Content | ||
Rainfall |
|
|
Wind Speed |
|
|
Wind Direction |
|
|
Outdoor Temperature |
|
|
Outdoor Humidity |
|
|
Power | ||
Solar power supply |
|
|
Power cord supply |
|
|
Battery supply |
|
|
Extra battery pack supported |
|
|
Compatibility Instructions
for all ecowitt network consoles
Please follow the table to make sure you choose the right sensors and concoles before check out.
Note: The "1/4/8/16" means 1 console supports 1/4/8/16 sensors
( excluding accessories )
