WN1980_C Wi-Fi Console, 5.3'' LCD Display, Built-in Indoor Temperature, Humidity and Barometric Sensor Antenna, Touch Screen Key
WN1980_C Wi-Fi Console, 5.3'' LCD Display, Built-in Indoor Temperature, Humidity and Barometric Sensor Antenna, Touch Screen Key
4.5 / 5.0
(2) 2 total reviews
Couldn't load pickup availability
Features
WLAN gateway; Barometric; Temperature; Humidity;
Although WN1980 could be as Wi-Fi gateway to pair with all ecowitt sensors and upload their data to Internet, only some sensors' data could display on WN1980 console, such as 8 channels WN30/WN31/WN36, WN32 outdoor sensor and WH40 rain gauge sensor. By the way, WS90's temperature, humidity, wind speed/direction, rainfall data and WS68's wind speed/direction data could display on WN1980, while their UV&Light data Not.
Services
Website page: ecowitt.net; 192.168.4.1;
APP: Ecowitt;
Weather servers support: Wunderground; Weathercloud; WeatherObservationWebsite; Customized (Homeseer; Homeassistant;)
Specifications
| Measurement | Range | Accuracy | Resolution |
| Barometric | 300 to 1100 hPa (8.85 to 32.5 inHg) | ± 5hPa | 0.1hPa (0.01 inHg) |
| Temperature (Indoor) | -10°C to 60°C (-14°F to 140°F) | ± 0.3°C (± 0.6°F) | 0.1°C (0.1°F) |
| Humidity (Indoor) | 1% to 99% | ± 3.5% | 1% |
Power supply: Type-C power cable
Backup power: 2 X AA batteries (Support Min.48 hours working)
Transmission between gateway and Wi-Fi router
Transmission distance in open field: 50 m (165 ft.) depending on router and environment
RF Frequency: 2.4 GHz
WLAN and Ethernet: 802.11 b/g/n
Updates on the Internet: Customize 1-5 minutes (recommend 1 minute)
Parts List
1* WN1980_C Display/Gateway/Console
1* Type-C power cable
Additional or optional or extra or compatible with sensors (sold separately):
One WN1980 supports one WS90 sensor;
One WN1980 supports one WS80 sensor;
One WN1980 supports one WS69 sensor;
One WN1980 supports one WS68 sensor;
One WN1980 supports one WH40 sensor;
One WN1980 supports one WN32 sensor;
One WN1980 supports one WH45 sensor or WH46 sensor;
One WN1980 supports one WH57 sensor;
One WN1980 supports up to four WH41 sensors or WH43 sensors;
One WN1980 supports up to four WH55 sensors;
One WN1980 supports up to eight WN30 sensors or WN31 sensors or WN36 sensors;
One WN1980 supports up to eight WN34 sensors or WN34S sensors or WN34L sensors or WN34D sensors;
One WN1980 supports up to eight WH51 sensors or WH51L sensors;
One WN1980 supports up to sixteen WFC01 sensors or AC1100 sensors;
