HP2561

Regular price $213.99 USD
Regular price Sale price $213.99 USD
Sale Sold out
Shipping & Tax calculated at checkout.

Work with other sensors and consoles

Additional/optional about sensors and consoles

A table to learn combination of different models

Linking frequency about sensors and consoles

A listing to learn choosing frequency in different country

Features

Sensor: Rain gauge; Wind speed, gust speed, and wind direction;

Temperature; Humidity; Solar light intensity and UV index;

Indoor display: WLAN gateway; Barometric; Temperature; Humidity;


Services

Website page: ecowitt.net;

APP: Ecowitt; Ecowitt view plus;

API: Wunderground; Weathercloud; WeatherObservationWebsite; Customized (Homeseer; Homeassistant;)


Specifications (WS69 Sensor)

Measurement Range Accuracy Resolution
Wind speed 0m/s to 50m/s

±1 m/s (speed < 10 m/s);

± 10% (speed ≥ 10 m/s)

0.1m/s
Wind direction 0° to 359° ± 15°
Temperature -40°C to 60°C ±0.3°C (± 0.6°F) 0.1°C (± 0.1°F)
Humidity 1% to 99% ±3.5% 0.01
Light 0Klux to 200Klux ±25% 0.1Klux
UVI 1~15 ±2 1
Rain 0~9999 ± 10%

0.3 mm (for volume < 1,000 mm);

1 mm (for volume ≥ 1,000 mm

Sensor (backup): 2 x AA 1.5V battery (not included)

Sensor solar panel (built-in): 6.5V/4mA


Transmission between gateway and sensor

Transmission distance in open field: 100 m (330 ft.)

RF frequency: 433/868/915 MHz depending on location

Updates on the gateway: 16s


Specifications (HP2560_C display)

Measurement Range Accuracy Resolution
Barometric 300 to 1100 hPa (8.85 to 32.5 inHg) ± 5hPa 0.1hPa (0.01 inHg)
Temperature (Indoor) -10°C to 60°C (-14°F to 140°F) ± 0.3°C (± 0.6°F) 0.1°C (0.1°F)
Humidity (Indoor) 1% to 99% ± 3.5% 1%

USB to 2.5*0.7mm DC 5V power plug connector cable: 5V ⎓ 1.0A 5.0W


Transmission between gateway and Wi-Fi router

Transmission distance in open field: 50 m (165 ft.) depending on router and environment

RF Frequency: 2.4 GHz

WLAN and Ethernet: 802.11 b/g/n (802.11n, Max 150 Mbps)

Updates on the Internet: Customize 1-5 minutes (recommend 1 minute)


Parts List

1* HP2560_C Wi-Fi console/gateway/display

1* WS69 sensor

1* Wind speed cups (to be attached to outdoor sensor body)

1* Wind vane (to be attached to outdoor sensor body)

2* U-Bolts for mounting on a pole

4* Threaded nuts for U-Bolts (M5 size)

1* Metal mounting plate to be used with U-Bolts

1* Wrench for M5 bolts

1* Power cord

1* User Manual
