WS80
WS80
Couldn't load pickup availability
Features
Outdoor temperature and humidity
Ultrasonic Wind speed, gust speed, and wind direction
Solar light intensity and UV index
Specifications
|
Measurement |
Range |
Accuracy |
Resolution |
|
Wind speed |
0~40m/s |
<10m/s, +/-0.5m/s ≥10m/s, +/-5% |
0.1M/S |
|
Wind direction |
0~359° |
<10m/s, TBA ≥10m/s, ±15° |
1° |
|
Temperature |
-40~60℃ |
±1℃ |
0.1℃ |
|
Humidity |
1~99% |
±5% |
1% |
|
Light |
0~300Klux |
±15% |
10Lux |
|
UVI |
1~15 |
±2 |
1 |
| Maximum wind speed of the last 4s is >=5m/s, | the wind speed is detected by 1s; |
| Maximum wind speed of the last 4s is >=3m/s and less than 5m/s, | the wind speed is detected by 2s; |
| Maximum wind speed of the last 4s is <3m/ s, | the wind speed is detected by 4s. |
| Wind speed is lower than 5m/s | the dispersion of wind direction will increase. |
| Note | The wind speed reading will be a real-time value (The latest sampling data will be reporting to the receiver). |
Specifications (Transmission)
| RF Frequency: | 915/868/433 MHz(North America: 915MHz; Europe: 868MHz; Other areas: 433MHz) |
| Transmission distance in open field: | 300m(1000 ft) for RF Frequency 915/868MHz 200m(600ft) for RF Frequency 433MHz |
| Sensor reporting interval: | 4.8 seconds |
Specifications (Power)
|
Anemometer sensor |
Solar panel (built-in): 6.5V/4mA |
|
Anemometer sensor (backup) |
2 x AA 1.5V Lithium battery (not included) |
Parts List
|
1 |
Solar powered ultrasonic anemometer with Light and UV, air temperature/humidity sensor integrated( optional heater for climate with snow/ice conditions available) |
|
1 |
U-Bolts set for mounting on a pole (2pcs/set) |
|
1 |
Threaded nuts for U-Bolts set (M6 size) (4pcs/set) |
|
1 |
Mounting arm for ultrasonic anemometer |
|
1 |
Mounting bracelet for ultrasonic anemometer |
|
1 |
User manual (this manual) |
Packaged information
Length * Width * Height: 36*16*12cm
Weight: 1300g
Battery: None
