WS3910_C Wi-Fi Console, 7.5'' LCD Display with Built-in CO₂ Detector and IOT Intelligent Linkage Control
Couldn't load pickup availability
Features:
- Wi-Fi enabled, 7.5" LCD color display, 8 physical buttons.
- Support DC powered and 3 x AA Alkaline / Lithium batteries powered (Batteries not included).
- Calendar, date, time, moon phase, sunrise, sunset, alarm & snooze, DST (Daylight Saving Time), 5 levels backlight adjustable, unit setting, record max & min value, RST function (Clear daily max/min values).
- Built-in temperature humidity sensor, barometric pressure sensor and CO₂ sensors.
- Support receiving and displaying 8 channels temperature and humidity, wind speed, wind direction, rainfall, UV, solar radiation, feels like, dew point, CO₂, PM1.0, PM2.5, PM10, and AQI data.
- Weather forecast: Sunny, Partly Cloudy, Cloudy, Rainy, Stormy, Snowy and Storm Snowy.
- Can be used as a Wi-Fi gateway to support the reception of more sensors’ data, which can be viewed through the web page.
- Support Wi-Fi configuration via Ecowitt App & Web page(192.168.4.1).
- Support uploading data to the weather station server after
connecting to the Wi-Fi network:
■ ecowitt.net (Default upload to this server)
■ wunderground.com
■ weathercloud.net
■ wow.metoffice.gov.uk
■ Customized servers - Data storage and download on Ecowitt server: https://ecowitt.net.
Specifications:
|
Model |
WS3910 |
|
Name |
Weather Station (receiver) |
|
Dimensions |
209×28.5×142.5(mm) |
|
Screen Size |
169×94.5(mm) |
|
Weight |
366(g) |
|
Material of Plastic Casing |
ABS |
|
Material of Screen |
VA-LCD |
|
Temperature Metering Range |
-9.9°C to 60°C(14°F to 140°F) |
|
Temperature Metering Accuracy |
±0.2°C(±0.4℉) |
|
Temperature Metering Resolution |
0.1°C(0.2℉) |
|
Humidity Metering Range |
1% to 99% |
|
Humidity Metering Accuracy |
±2% |
|
Humidity Metering Resolution |
1% |
|
Barometric Pressure Metering range |
300 to 1100 hPa (8.85 to 32.5 inHg) |
|
Barometric Pressure Metering accuracy |
±1.5hpa(absolute pressure ); ±2hpa(relative pressure) |
|
Barometric Pressure Metering resolution |
0.1 hPa (0.01 inHg) |
|
Photoacoustic NDIR CO₂ Metering range |
0 to 40000 ppm |
|
Photoacoustic NDIR CO₂ Metering accuracy |
±(50ppm + 5% of reading) when 400 to 2000 ppm |
|
Photoacoustic NDIR CO₂ Metering resolution |
1ppm |
|
Photoacoustic NDIR CO₂ Accuracy drift per year |
± (5ppm + 5% of reading) |
|
Reading Update Interval |
About 1 minute |
|
RF Connection Frequency |
915/868/433MHz (depending on local regulations) |
|
RF Wireless Range |
Over 100 meters (in open areas) |
|
WLAN |
802.11 b/g/n 2.4 GHz |
|
Power Supply |
DC 5V 1A or 3 AA Alkaline or Lithium Battery (not included) |
|
Battery Life |
15-25 days (Back-up only) |
Package Included:
1 x WS3910 Weather Station Receiver
1 x User Manual
1 x DC to USB Cable
| Measurements | ||
|---|---|---|
Relative Pressure |
|
|
Indoor Humidity |
|
|
Indoor Temperature |
|
|
CO₂ |
|
—
|
| Power | ||
Power cord supply |
|
|
Battery supply |
|
|
| Connection & Data | ||
Wi-Fi (2.4G only) |
|
|
Radio Frequency (RF) |
|
|
| Addable | ||
Ecowitt IoT Device |
|
|
Ecowitt Sensor |
|
|
Compatibility Instructions
for all ecowitt network consoles
Please follow the table to make sure you choose the right sensors and concoles before check out.
Note: The "1/4/8/16" means 1 console supports 1/4/8/16 sensors
( excluding accessories )
