The Ecowitt AC1100 is a brand new smart plug that is compatible with the Ecowitt IoT ecosystem. When paired with the Ecowitt IoT gateway, it allows remote control of power on/off, energy consumption tracking, remote alarms, and more. Additionally, it features a smart mode, enabling home appliance automation based on preset conditions. Please note that the AC1100 needs to be used inconjunction with the Ecowitt IoT gateway and can’t be used as a standalone product. The following User Manual provides step by step instructions for installation and operation.
Compatible gateways / consoles (Wi-Fi and/or Cellular): GW1200/GW2000/GW3000/WS6210/WS3800/WS3820/WS3900/WS3910/WN1920/WN1980/WN1820/WN1821/WN1700
Note:
1. The sensor may share the same channels with other sensors of the same type.
2. Some data is cloud-only and not available on compatible consoles.
3. Compatibility may change with product updates. Please refer to the latest compatibility table(at the bottom of the product page) or contact us for confirmation.
Specification:
| Model | AC1100 |
| Name | WittSwitch Smart Plug |
| Version | American Regulation |
| Dimensions | 62.0×56×110(mm) |
| Weight | 118g |
| Material of Plastic Casing | PC |
| RF Connection Frequency | 915MHz |
| RF Wireless Range | Over 100 meters (in open areas) |
| Power-on current | ≤ 80mA |
| Static current | ≤ 15mA |
| Input Voltage | 125VAC |
| Max Current | 12A |
| Max Power | 1440W |
| Power Meter Accuracy | ±2% |
| Model | AC1100 |
| Name | WittSwitch Smart Plug |
| Version | Australia Regulation |
| Dimensions | 62.0×64×110(mm) |
| Weight | 118g |
| Material of Plastic Casing | PC |
| RF Connection Frequency | 433MHz |
| RF Wireless Range | Over 90 meters (in open areas) |
| Power-on current | ≤ 80mA |
| Static current | ≤ 15mA |
| Input Voltage | 100—240VAC |
| Max Current | 10A |
| Max Power | 2300W |
| Power Meter Accuracy | ±2% |
| Model | AC1100 |
| Name | WittSwitch Smart Plug |
| Version | British Regulation |
| Dimensions | 62.0×65×110(mm) |
| Weight | 137g |
| Material of Plastic Casing | PC |
| RF Connection Frequency | 868MHz |
| RF Wireless Range | Over 100 meters (in open areas) |
| Power-on current | ≤ 80mA |
| Static current | ≤ 15mA |
| Input Voltage | 100—240VAC |
| Max Current | 13A |
| Max Power | 3000W |
| Power Meter Accuracy | ±2% |
| Model | AC1100 |
| Name | WittSwitch Smart Plug |
| Version | European Regulation |
| Dimensions | 62.0×72×110(mm) |
| Weight | 130g |
| Material of Plastic Casing | PC |
| RF Connection Frequency | 868MHz |
| RF Wireless Range | Over 100 meters (in open areas) |
| Power-on current | ≤ 80mA |
| Static current | ≤ 15mA |
| Input Voltage | 100—240VAC |
| Max Current | 16A |
| Max Power | 3500W |
| Power Meter Accuracy | ±2% |
Package List:
1 x AC1100
1 x Manual
Compatibility Instructions
for all ecowitt network consoles
Please refer to the table to choose the correct sensors and consoles before checkout.
Note:
1) "1/4/8/16" = max number of sensors supported per console (excluding accessories).
2) Upload only = sensor readings shown only in the Ecowitt app and cloud (www.ecowitt.net).
3) Firmware (e.g. V1.9.6 / V2.0.2) = gateway/console must run this version or newer.
