WS80

Regular price $109.99 USD
Regular price Sale price $109.99 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

Choose different sensors and consoles

Additional/optional about sensors and consoles

A table to learn combination of different models

Linking frequency about sensors and consoles

A listing to learn choosing frequency in different country

Features
Outdoor temperature and humidity
Ultrasonic Wind speed, gust speed, and wind direction
Solar light intensity and UV index

Specifications

Measurement

Range

Accuracy

Resolution

Wind speed

0~40m/s

<10m/s, +/-0.5m/s

≥10m/s, +/-5%

0.1M/S

Wind direction

0~359°

<10m/s, TBA

≥10m/s, ±15°

Temperature

-40~60℃

±1℃

0.1℃

Humidity

1~99%

±5%

1%

Light

0~300Klux

±15%

10Lux

UVI

1~15

±2

1



Maximum wind speed of the last 4s is >=5m/s,  the wind speed is detected by 1s;
Maximum wind speed of the last 4s is >=3m/s and less than 5m/s,  the wind speed is detected by 2s;
Maximum wind speed of the last 4s is <3m/ s,  the wind speed is detected by 4s.
Wind speed is lower than 5m/s the dispersion of wind direction will increase.
Note The wind speed reading will be a real-time value (The latest sampling data will be reporting to the receiver).



Specifications (Transmission)

RF Frequency:  915/868/433 MHz(North America: 915MHz; Europe: 868MHz; Other areas: 433MHz)
Transmission distance in open field: 300m(1000 ft) for RF Frequency 915/868MHz
200m(600ft) for RF Frequency 433MHz
Sensor reporting interval:  4.8 seconds





Specifications (Power)

Anemometer sensor

Solar panel (built-in): 6.5V/4mA

Anemometer sensor (backup)

2 x AA 1.5V Lithium battery (not included)



Parts List

1

Solar powered ultrasonic anemometer with Light and UV, air temperature/humidity sensor integrated( optional heater for climate with  snow/ice conditions available)

1

U-Bolts set for mounting on a pole (2pcs/set)

1

Threaded nuts for U-Bolts set (M6 size) (4pcs/set)

1

Mounting arm for ultrasonic anemometer

1

Mounting bracelet for ultrasonic anemometer

1

User manual (this manual)


Packaged information
Length * Width * Height: 36*16*12cm
Weight: 1300g
Battery: None
